Features

• Drop in design cage (Solid and Easy to Remove)

• 4 Tie Down Rails are Welded All The Way Around

• Front and rear opening tailgates

• Extended foot step for easy access to load

• Fully Welded Body

• Reinforced Chassis & Hinges

• Greasable Rocker Roller Suspension

• Electric Brake On 4 Wheels

Specifications

• Drawbar - 1800mm  100x50x3.0mm Tube

• Chassis Frame - 70x50x3.0mm Tube

• Finish - Hot Dipped Galvanised (Rust free)

• Side - 300mm High (One Piece of Checker Plate Fold Up)

• Floor - 2.5mm 2 Piece of Fully Welded Checker Plate

• Cage - 600mm (Drop In Design)

• Jockey Wheel - 8" Steel Rim Swing up

• Tyre - Brand New 15" 195/R15LT Light Truck

• Wheel - Sunraysia Style with 6 Studs Pattern

• Axle - 50x50mm Square Solid With Heavy Duty
• Parallel Bearings

• Suspension - Heavy Duty Greasable Rocker Roller Suspension

• Spring - 60X7mm Heavey Duty 7 Leaf Eye to Eye Spring

• Coupling - 50mm ADR Approved Australia Standard with Grease Nipples

• Trailer plug - flat 7 pin (round optional)
• Safety Chain - 13mm

• Brake - Electric Brakes on All 4 Wheels with
• Breakaway Unit

• Light - LED Set

External Sizes

• 8 x 5: 4480 x 2050mm

• 9 x 5: 4780 x 2050mm

• 10 x 5: 5080 x 2050mm

• 10 x 6: 5080 x 2350mm

• 12 x 6:5680 x 2350mm


Internal Sizes

•  8 x 5:  2430 x 1520mm

•   9 x 5: 2730 x 1520mm

• 10 x 5: 3030 x 1520mm

• 10 x 6: 3040 x 1820mm

• 12 x 6: 3640 x 1820mm

External Sizes

• 8 x 5: 4480 x 2050mm

Internal Sizes

•  8 x 5:  2430 x 1520mm

Features

• 450mm High Side

• Drop in design cage (Solid and Easy to Remove)
• 4 Tie Down Rails are Welded All The Way Around

• Front and rear opening tailgates
• Extended foot step for easy access to load
• Fully Welded Body

• Reinforced Chassis & Hinges

• Greasable Rocker Roller Suspension

• Electric Brake On 4 Wheels

Specifications

• Drawbar - 1800mm 100x50x3.0mm Tube

• Chassis Frame - 70x50x3.0mm Tube

• Finish - Hot Dipped Galvanised (Rust free)

• Side - 450mm High (One Piece of Checker Plate Fold Up)

• Floor - 2.5mm 2 Piece of Fully Welded Checker Plate

• Cage - Optional 600mm/900mm Cage (Drop In Design)

• Jockey Wheel - 8" Steel Rim Swing up

• Tyre - Brand New 15" 195/R15LT Light Truck

• Wheel - Sunraysia Style with 6 Studs Pattern

• Axle - 50x50mm Square Solid With Heavy Duty Parallel Bearings

• Suspension - Heavy Duty Greasable Rocker Roller Suspension

• Spring - 60X7mm Heavy Duty 7 Leaf Eye to Eye Spring

• Coupling - 50mm ADR Approved Australia Standard with
• Grease Nipples

• Trailer plug - flat 7 pin (round optional)
• Safety Chain - 13mm

• Brake - Electric Brakes on All 4 Wheels with Breakaway Unit

• Light - LED Set
